Coil former

Material:

GFR thermosetting plastic (UL 94 V-0, insulation class to IEC 60085:

F

max. operating temperature 155

°C), color code green

Solderability: to IEC 60068-2-20, test Ta, method 1 (aging 3): 235

°C, 2 s

Resistance to soldering heat: to IEC 60068-2-20, test Tb, method 1B: 350

°C, 3,5 s

Winding:

see “Processing Notes”, page 153

Squared pins

For matching clamp and insulating washers see page 255

10 pins

12 pins

Sections

mm

µΩ

Pins

Ordering code

1

107

71,5

23

10

B65888-C1010-D1

12

B65888-C1012-D1

FRM0273-D

3

15,2+0,3

0,6

Erdungspunkte ø1,6+0,1

1

2

3

12

11

10

9

7

4

6

7

9

6 4

10

11

12

1

2

3

8

5

0,3

_

ø16,8 0,2

Ground Ø 1,6+0,1

Hole arrangement

View in mounting direction

B65888

Accessories

RM 14
