Product Search Data Sheet

SFECF10M7DF00S0-R0

Note: This datasheet may be out of date.

Please download the latest datasheet of SFECF10M7DF00S0-R0 from the official website of Murata

Manufacturing Co., Ltd.

http://www.murata.com/en/products/productdetail?partno=SFECF10M7DF00S0-R0

Attention

1.This datasheet is downloaded from the website of Murata Manufacturing Co., Ltd. Therefore, it’s specifications are subject to change or our products in it may be discontinued

without advance notice. Please check with our sales representatives or product engineers before ordering.

2.This datasheet has only typical specifications because there is no space for detailed specifications.

Therefore, please review our product specifications or consult the approval sheet for product specifications before ordering.

URL : https://www.murata.com/

Last updated04/09/2024

Specifications

Operating Temperature

Range

-40

℃ to 85℃

Shape

SMD

Elements

2

Center Frequency

10.700MHz

Nominal Center Value

Yes

3dB Bandwidth

fn±145kHzmin.

Stop Bandwidth

990kHz

Area of Stop Bandwidth

[within 20dB]

Spurious Attenuation

20dB[within 9MHz to fn]

Insertion Loss

6.0dBmax. [at fn](at minimum

loss point)

Ripple

3.0dBmax.(at minimum loss

point)

Input/Output Impedance

330Ω

Mass

65mg

2 of 3
