 3 / 4 page
background image
ISG2018
eq STGP30M65DF2
Trench gate Field-Stop IGBT
www.iscsemi.com
2023-10-09
3
SYMBOL
PARAMETER
CONDITIONS
MIN
TYPE
MAX
UNIT
td(on)
Turn-on Delay Time
VGE = 15V,
IC= 30A,
VCE = 400V,
RG=10Ω
TJ=25℃
--
31.6
--
ns
tr
Turn-on Rise Time
--
13.4
--
ns
(di/dt)on
Turn-on current slope
--
1791
--
A/µs
td(off)
Turn-off Delay Time
--
115
--
ns
tf
Turn-off Fall Time
--
110
--
ns
Eon
Turn-on switching losses
--
0.3
--
mJ
Eoff
Turn-off switching losses
--
0.96
--
mJ
Ets
Total switching losses
--
1.26
--
mJ
td(on)
Turn-on Delay Time
VGE = 15V,
IC= 30A,
VCE = 400V,
RG=10Ω
TJ=175℃
--
30
--
ns
tr
Turn-on Rise Time
--
17
--
ns
(di/dt)on
Turn-on current slope
--
1435
--
A/µs
td(off)
Turn-off Delay Time
--
116
--
ns
tf
Turn-off Fall Time
--
194
--
ns
Eon
Turn-on switching losses
--
0.67
--
mJ
Eoff
Turn-off switching losses
--
1.36
--
mJ
Ets
Total switching losses
--
2.03
--
mJ
