L3380
CMOS IC
UNISONICTECHNOLOGIESCO.,LTD
2 of 9
www.unisonic.com.tw
QW-R502-099,A
MARKING INFORMATION
PACKAGE
VOLTAGE CODE
MARKING
SOT-25
18:1.8V
21:2.1V
25:2.5V
27:2.7V
30:3.0V
33:3.3V
40:4.0V
50:5.0V
5
4
3
Voltage Code
21
H 0
Lead Plating
PIN DESCRIPTION
PIN
NAME
FUNCTION
1
SHUTDOWN
Shutdown control input, “H” : normal operation
“L” : stop step up( whole circuit stop).
2
VOUT
Power supply and voltage output.
3
NC
No connection.
4
VSS
Ground.
5
EXT
Switching the circuit by connecting to a transistor.
