PT6302 v1.4

- 1 -

April, 2004

VFD Driver/Controller IC with Character RAM

PT6302

DESCRIPTION

PT6302 is a dot matrix VFD Driver/Controller IC utilizing CMOS Technology specially designed to

display characters, numerals, and symbols. PT6302 provides 35 dot matrix plus 2 additional segment

drivers and 16 grid drivers. 248 types of character data (CGROM), 8 types of character data (CGRAM),

16 display digits x 2 bits symbol data, 16 display digits x 8 bits register for character data display and 2

general output bits for static operation are provided. Pin assignments and application circuit are

optimized for easy PCB layout and cost saving advantages.

FEATURES

• CMOS Technology

• Logic Power Supply: VDD = 3.3 V ± 10% or 5.0 V ± 10%

• VFD Drive Power Supply: VEE = -20V to -30V

• Built-in Oscillation Circuit (External RC)

• One-Byte Instruction Execution (not including Data Write to RAM)

• Microcontroller Interface

• Display Contents:

o

Character Generator ROM (CGROM): 5x7 Dots (248 Character Data Types)

o

Character Generator RAM (CGRAM): 5x7 Dots (8 Character Data Types)

o

Additional Data RAM (ADRAM): 16 Display Digits x 2 Bits (Symbol Data)

o

Data Control RAM (DCRAM): 16 Display Digits x 8 Bits (Character Data Display

Register)

o

General Output Port: 2 Bits (Static Operation)

• Display Control Function:

o

Display Digits : 9 to 16 Digits

o

Display Duty (Contrast Adjustment) : 8 stages

o

All Display Lights : ON/OFF Mode

APPLICATIONS

• Microcontroller Peripheral Device

• Audio/Video Equipment
