background image
AD8190
Rev. 0 | Page 7 of 24
Pin No.
Mnemonic
Type1
Description
34
IN_B1
HS I
High Speed Input Complement.
35
IP_B1
HS I
High Speed Input.
37
IN_B2
HS I
High Speed Input Complement.
38
IP_B2
HS I
High Speed Input.
40
IN_B3
HS I
High Speed Input Complement.
41
IP_B3
HS I
High Speed Input.
43
AUX_B3
LS I/O
Low Speed Input/Output.
44
AUX_B2
LS I/O
Low Speed Input/Output.
45
AUX_B1
LS I/O
Low Speed Input/Output.
46
AUX_B0
LS I/O
Low Speed Input/Output.
47
AMUXVCC
Power
Positive Auxiliary Switch Supply. 5 V typical.
48
AUX_COM3
LS I/O
Low Speed Common Input/Output.
49
AUX_COM2
LS I/O
Low Speed Common Input/Output.
50
AUX_COM1
LS I/O
Low Speed Common Input/Output.
51
AUX_COM0
LS I/O
Low Speed Common Input/Output.
52
DVEE
Power
Negative Digital and Auxiliary Switch Power Supply. 0 V nominal.
53
AUX_A3
LS I/O
Low Speed Input/Output.
54
AUX_A2
LS I/O
Low Speed Input/Output.
55
AUX_A1
LS I/O
Low Speed Input/Output.
56
AUX_A0
LS I/O
Low Speed Input/Output.
1 HS = high speed, LS = low speed, I = input, O = output.
