ADL5530

Rev. 0 | Page 3 of 12

SPECIFICATIONS

VPOS = 5 V and TA = 25°C, unless otherwise noted.

Table 1.

Parameter

Conditions

Min

Typ

Max

Unit

OVERALL FUNCTION (See Table 2)

Frequency Range1

1000

MHz

Gain (S21)

16.5

Input Return Loss (S11)

−11

Output Return Loss (S22)

−20

Reverse Isolation (S12)

−21.5

FREQUENCY = 70 MHz

Gain

16.7

vs. Temperature

−40°C ≤ TA ≤ +85°C

±0.1

vs. Supply

4.75 V to 5.25 V

±0.02

Output 1 dB Compression Point

21.7

dBm

Output Third-Order Intercept

∆f = 10 MHz , Output Power (POUT)= 10 dBm per tone

dBm

Noise Figure

VPOS = 3 V

3.2

FREQUENCY = 190 MHz

Gain

16.8

18.5

vs. Frequency

± 50 MHz

±0.1

vs. Temperature

−40°C ≤ TA ≤ +85°C

±0.2

vs. Supply

4.75 V to 5.25 V

±0.02

Output 1 dB Compression Point

21.8

dBm

Output Third-Order Intercept

∆f = 10 MHz , POUT = 10 dBm per tone

dBm

Noise Figure

4.5

VPOS = 3 V

2.3

FREQUENCY = 380 MHz

Gain

14.8

17.3

vs. Frequency

± 50 MHz

±0.1

vs. Temperature

−40°C ≤ TA ≤ +85°C

±0.3

±0.8

vs. Supply

4.75 V to 5.25 V

±0.02

Output 1 dB Compression Point

19.5

21.6

dBm

Output Third-Order Intercept

∆f = 10 MHz , POUT = 10 dBm per tone

dBm

Noise Figure

2.5

3.5

VPOS = 3 V

FREQUENCY = 900 MHz

Gain

14.5

vs. Frequency

± 50 MHz

±0.2

vs. Temperature

−40°C ≤ TA ≤ +85°C

±0.5

±1

vs. Supply

4.75 V to 5.25 V

±0.02

Output 1 dB Compression Point

21.4

dBm

Output Third-Order Intercept

∆f = 10 MHz , POUT = 10 dBm per tone

dBm

Noise Figure

2.7

3.5

VPOS = 3 V

2.3

POWER INTERFACE

Pin VPOS

Supply Voltage (VPOS)

5.5

Supply Current

110

135

vs. Temperature

−40°C ≤ TA ≤ +85°C

±5

Power Dissipation

VPOS = 5 V

0.55

VPOS = 3 V

0.33

1 For operation at lower frequencies, see the Theory of Operation section.
