TH-32A400H TH-32A410H
26
8 Measurements and Adjustments
8.1.
Voltage chart of A-board
Set A-Board to a dummy set and check the satisfaction with the specified voltage as following table.
8.2.
Voltage chart of P-board
Set P-Board to a dummy load and check the satisfaction with the specified voltage as following table.
Power Supply Name
Measurement Point
Specification (V)
Remark
SUB1.2V
TP8004
1.14 - 1.26
-
SUB3.3V
TP8003
3.19 - 3.46
-
SUB5V
TP8002
4.92 - 5.25
-
STB5V
TP8009
5.3 ± 0.3
-
PNL12V
TP4300
11.5 - 12.5
-
Output
Test Point
Specification
Operate
Stby
5.3V
TP7507
5.3 ± 0.3V
5.3 ± 0.3V
16V
TP7512/TP7513
15.8 ± 0.6 V
-
