ADL8142ACPZN-R7-CSL Datasheet(PDF) 4 Page - Analog Devices

No. de pieza ADL8142ACPZN-R7-CSL
Descripción Electrónicos  GaAs, pHEMT, MMIC, Low Noise Amplifier, 23 GHz to 31 GHz
PDF  8 Pages
Scroll/Zoom Zoom In 100%  Zoom Out
Fabricante Electrónico  AD [Analog Devices]
Página de inicio  http://www.analog.com
Logo AD - Analog Devices

ADL8142ACPZN-R7-CSL Datasheet(HTML) 4 Page - Analog Devices

  ADL8142ACPZN-R7-CSL Datasheet HTML 1Page - Analog Devices ADL8142ACPZN-R7-CSL Datasheet HTML 2Page - Analog Devices ADL8142ACPZN-R7-CSL Datasheet HTML 3Page - Analog Devices ADL8142ACPZN-R7-CSL Datasheet HTML 4Page - Analog Devices ADL8142ACPZN-R7-CSL Datasheet HTML 5Page - Analog Devices ADL8142ACPZN-R7-CSL Datasheet HTML 6Page - Analog Devices ADL8142ACPZN-R7-CSL Datasheet HTML 7Page - Analog Devices ADL8142ACPZN-R7-CSL Datasheet HTML 8Page - Analog Devices
Zoom Inzoom in Zoom Outzoom out
 4 / 8 page
background image
Data Sheet
ADL8142S
SPECIFICATIONS
analog.com
Rev. 0 | 4 of 8
RADIATION TEST AND LIMIT SPECIFICATIONS
Electrical characteristics at VDD = 2 V, IDQ = 25 mA, RBIAS = 634 Ω, and TC = 25°C, unless otherwise noted. Total ionizing dose (TID) testing
characterized to 30 krads.
Table 4.
Parameter
Min
Typ
Max
Unit
FREQUENCY RANGE
27
31
GHz
GAIN
24.5
27
GHz
OUTPUT
P1dB
7
10
dBm
SUPPLY CURRENT
IDQ
25
mA
SUPPLY VOLTAGE
VDD
1.5
2
3.5
V
