MRLM101A-X-RH REV 1B2

MICROCIRCUIT DATA SHEET

Electrical Characteristics

DC PARAMETERS: DRIFT VALUES

(The following conditions apply to all the following parameters, unless otherwise specified.)

DC:

+Vcc = +20V, Vcm = 0V, Rs = 50 Ohms.

"Delta calculations performed on JAN S and QMLV devices at group

B, subgroup 5 only".

SYMBOL

PARAMETER

CONDITIONS

NOTES

PIN-

NAME

MIN

MAX

UNIT

SUB-

GROUPS

Vio

Input Offset

Voltage

Vcm = 0V

-0.5

0.5

mV

1

Iib+

Input Bias

Current

Vcm = 0V, Rs = 100K Ohms

-7.5

7.5

nA

1

Iib-

Input Bias

Current

Vcm = 0V, Rs = 100K Ohms

-7.5

7.5

nA

1

Note 1:

Calculated parameter.

Note 2:

Datalog reading of K = V/mV.

Note 3:

Pre and post irradiation limits are identical to those listed under AC and DC

electrical characteristics except as listed in the Post Radiation Limits Table. These

parts may be dose rate sensitive in a space environment and demonstrate enhanced low

dose rate effect. Radiation end point limits for the noted parameters are guaranteed

only for the conditions as specified in MIL-STD-883, Method 1019.5

7
