Preliminary

PLL601-26

Audio Clock Generator

47745 Fremont Blvd., Fremont, California 94538 TEL (510) 492-0990 FAX (510) 492-0991 www.phaselink.com Rev 11/28/05 Page 3

DC SPECIFICATIONS

PARAMETERS

SYMBOL

CONDITIONS

MIN.

TYP.

MAX.

UNITS

Supply Current, Dynamic, with

Loaded Outputs

At 27MHz, load=15pF

15

mA

Operating Voltage

2.25

3.63

V

Output Low Voltage

0.4

V

Output High Voltage

0.4

V

Output Current

10

mA

Short-circuit Current

±50

mA

CRYSTAL SPECIFICATIONS

PARAMETERS

SYMBOL

MIN.

TYP.

MAX.

UNITS

Fundamental Crystal Resonator Frequency

27

MHz

Crystal Loading Rating

16

pF

Maximum Sustainable Drive Level

500

µW

Operating Drive Level

100

µW

Crystal Shunt Capacitance

C0

6

pF

Effective Series Resistance, Fundamental, 27MHz

ESR

30

Ω

Note: A detailed crystal specification document is also available for this part

JITTER SPECIFICATIONS

PARAMETERS

CONDITIONS

FREQUENCY

MIN.

TYP.

MAX.

UNITS

Cycle to Cycle Jitter

27MHz

300

ps

Cycle to Cycle Jitter

Audio Clock

150

ps
