PLL600-27/-37

Ultra Low Current XO 10 MHz to 52 MHz

47745 Fremont Blvd., Fremont, California 94538 Tel (510) 492-0990 Fax (510) 492-0991

www.phaselink.com Rev 08/12/04 Page 4

PACKAGE INFORMATION

C

L

A

8-PIN SOIC ( dimensions in mm )

E

H

D

A

1

e

B

Narrow SOIC

Symbol

Min.

Max.

A

1.47

1.73

A1

0.10

0.25

B

0.33

0.51

C

0.19

0.25

D

4.80

4.95

E

3.80

4.00

H

5.80

6.20

L

0.38

1.27

e

1.27 BSC

6-PIN SOIC ( dimensions in mm )
