Preliminary

PLL600-27F

Low Power 5 Output XO 10MHz to 52MHz

47745 Fremont Blvd., Fremont, California 94538 Tel (510) 492-0990 Fax (510) 492-0991 www.phaselink.com Rev 08/12/04 Page 2

PIN DESCRIPTION

Name

Pin #

Type

Description

XIN

1

I

Crystal Input or Reference Clock input ( 10MHz to 52MHz ).

GND

2,4,6,13

P

Ground.

CLK1

3

O

Buffered clock output.

CLK2

5

O

Buffered clock output.

N/C

7

-

No connection.

CLK3

8

O

Buffered clock output.

VDD

9,11

P

Power supply.

CLK4

10

O

Buffered clock output.

CLK5

12

O

Buffered clock output.

XOUT

14

O

Crystal output.

ELECTRICAL SPECIFICATIONS

1. Absolute Maximum Ratings

PARAMETERS

SYMBOL

MIN.

MAX.

UNITS

Supply Voltage

4.6

V

Input Voltage, dc

-0.5

V

Output Voltage, dc

-0.5

V

Storage Temperature

-65

150

°C

Ambient Operating Temperature*

-40

85

°C

Junction Temperature

125

°C

Lead Temperature (soldering, 10s)

260

°C

ESD Protection, Human Body Model

2

kV

Exposure of the device under conditions beyond the limits specified by Maximum Ratings for extended periods may cause permanent damage to the

device and affect product reliability. These conditions represent a stress rating only, and functional operations of the device at these or any other

conditions above the operational limits noted in this specification is not implied.

* Note: Operating Temperature is guaranteed by design for all parts (COMMERCIAL and INDUSTRIAL), but tested for COMMERCIAL grade only.

2. AC Electrical Specifications

PARAMETERS

CONDITIONS

MIN.

TYP.

MAX.

UNITS

Input Crystal Frequency

10

52

MHz

Settling time

At power-up

(Vdd reaches 1.62V)

10

ms

0.8V ~ 2.0V with 10 pF load

1.15

Output Clock Rise/Fall Time

0.3V ~ 3.0V with 15 pF load

2.4

ns

VDD sensitivity

Frequency vs. VDD +/- 10%

0.8

0.8

ppm

Output Clock Duty Cycle

Measured @ 1.4V

45

50

55

%

Short Circuit Current

±50

mA
