MODEL: W2PV

W2PV SPECIFICATIONS

ES-5544 Rev.13 Page 3/3

http://www.m-system.co.jp/

EXTERNAL DIMENSIONS & TERMINAL ASSIGNMENTS unit: mm (inch)

4

8 7

10

21.5 (.87)

84 (3.31)

12 (.47)

22 (.87)

DIN RAIL

35mm wide

[4 (.16)]

11–M3

SCREW

29.5 (1.16)

2–4.2x5

(.17x.20)

MTG HOLE

6 (.24) deep

114 (4.49)

11

5

6

1

2

3

9

6 (.23)

• When mounting, no extra space is needed between units.

PNEUMATIC COUPLER

(tube size 6 [.24] dia.)

SCHEMATIC CIRCUITRY & CONNECTION DIAGRAM

Base Socket

Semiconductor

Pressure Sensor

Low Drift

Amplifier

CONSTANT

CURRENT

INPUT

U(+)

V(–)

POWER

10

11

Note: The section enclosed by broken line is only with 2nd output option.

+

–

OUTPUT 1

+

–

Isolation

S

Z

Output

Driver

S

Z

Output

Driver

OUTPUT 2

7

8

3

6

Specifications are subject to change without notice.
