MODEL: KAS

KAS SPECIFICATIONS

ES-3525 Rev.3 Page 3/3

http://www.m-system.co.jp/

EXTERNAL DIMENSIONS unit: mm (inch)

3

4

5

6

2

1

8

7

50 (1.97)

103 (4.06)

123 (4.84)

[3.3 (.13)]

40 (1.57)

50 (1.97)

7.8 (.31)

CLAMP

(top & bottom)

DIN RAIL

35mm wide

MTG HOLE

15 (.59) deep

SCREW

• When mounting, no extra space is needed between units.

TERMINAL ASSIGNMENTS unit: mm (inch)

5

6

2

1

8

7

3

4

INPUT RESISTOR

(model: REM)

Input shunt resistor attached

for current input.

SCHEMATIC CIRCUITRY & CONNECTION DIAGRAM

Output

Driver

D / A

Converter

Oscillator

Comparator

Low Drift

Amplifier

+

–

Gate

Isolation

Base Socket

S

Z

*Input shunt resistor attached for current input.

UP / DOWN

Counter

OUTPUT

1

2

U(+)

V(–)

POWER

7

8

+

–

INPUT

3

4

R

*

5

6

(10 bits)

+V

HOLD CONTROL

Close

Open

: Track

: Hold

Specifications are subject to change without notice.
