HCMOS 2.5x2.0mm SMD Oscillator

O2HS

(former F200, F210, F230, F240 Series)

DATASHEET

7-27-2020 Updated Termination finish and MSL info

© Copyright 2020 Fox Electronics, All rights reserved

Title / Description: O2HS SERIES STANDARD SPECIFICATIONS

Drawing Number: O2HS-DOC-1

Revision: H

Part Number:

Cage: 61429

Draftsperson: BEC

Approved: MAJ

Revision Date:07/29/2020

Tape Specifications (millimeters)

Reel Specifications (millimeters)

A

B

C

D

E

F

Reel Qty

G

H

I

J

K

L

M

Ø1.55

4.0

4.0

3.5

8.0

1.15

-T3 = 3,000

-T2 = 2,000

-T1 = 1,000

2.0

Ø13

Ø21

Ø60

Ø180

9.0

2.0

Available Options & Part Identification*

Example: F O2HS B B M 25.0

F

O2HS

B

B

M

25.0

Fox

Model Number

Voltage

M = 1.0V±5%

I = 1.5V±5%

K = 1.8V±5%

H = 2.5V±5%

B = 3.3V±5%

V = 1.7 to 3.63V

W = 2.25 to 3.63V

Stability

A= ±100 PPM

B = ±50 PPM

D = ±25 PPM

E = ±20 PPM

Operating

Temperature

E = -10 to +70ºc

F = -20 to +70ºC

M = -40 to +85ºC

P = -40 to +105ºC

Frequency

(MHz)

*Not all frequencies in the frequency range, or every combination of stability, temp range, and voltage available. See stabilities and op temps for
