550 CATALOG No. C1097B001 '20.1.IT

PWM Controller

Output duty cycle controlled with variable resistor connected to terminals.

• Box type

• PCB type (Model no.: 9PC8045D-R001)

External adjustment (variable resistor) control

Variable resistor

DC power supply

+ GND

PWM signal

Variable resistor

DC power supply

+ GND

PWM signal

(%)

100

Resistance

(k )

Resistance -

Output Duty Cycle Characteristics

Recommended total resistance: 10 k

Resistance taper: B (linear curve tting)

Output duty cycle controlled with the adjustment knob.

• Box type

Internal adjustment (variable resistor) control

Output duty cycle controlled

with the adjustment knob (on the inner scale)

DC power supply

+ GND

PWM signal

(%)

100

Inner scale reading with adjustment knob

Inner Scale Reading -

Output Duty Cycle Characteristics
