Tightening torque max

0.6 Nm

Technical data

Range of articles

FRONT-MSTB 2,5/..-ST

Insulating material group

I

Rated surge voltage (III/3)

4 kV

Rated surge voltage (III/2)

4 kV

Rated surge voltage (II/2)

4 kV

Rated voltage (III/2)

320 V

Rated voltage (II/2)

630 V

Connection in acc. with standard

EN-VDE

12 A

250 V

Nominal cross section

2.5 mm²

Maximum load current

12 A

Insulating material

PA

Inflammability class acc. to UL 94

V0

Internal cylindrical gage

A3

Stripping length

10 mm

Nominal voltage, UL/CUL Use Group B

250 V

Nominal current, UL/CUL Use Group B

12 A

Nominal voltage, UL/CUL Use Group D

300 V

Nominal current, UL/CUL Use Group D

10 A

Connection data

Conductor cross section solid min.

0.34 mm²

Conductor cross section solid max.

2.5 mm²

Conductor cross section stranded min.

0.2 mm²

Conductor cross section stranded max.

2.5 mm²

Conductor cross section stranded, with ferrule

without plastic sleeve min.

0.25 mm²

Conductor cross section stranded, with ferrule

without plastic sleeve max.

2.5 mm²

Conductor cross section stranded, with ferrule

with plastic sleeve min.

0.25 mm²

Conductor cross section stranded, with ferrule

with plastic sleeve max.

2.5 mm²

Conductor cross section AWG/kcmil min.

24
