Product data sheet

Characteristics

QO2175SB

Surge Breaker - QO - 22.5kA -120/240VAC -

1P3W - T2

Product availability : Stock - Normally stocked in distribution facility

Price** : 159.00 USD

Main

Product

Secondary surge arrester

Range

Surge Breaker

QO

Complementary

Surge Current

22.5 kA

Voltage Rating

120/240 V AC

Number of Phases

1 phase

Wiring Configuration

3-wire

MCOV

150 V

300 V

SCCR

22 kA

Local Signalling

1 LED green normal operation

Product destination

Load center QO

Height

3.7 in (93.98 mm)

Width

1.5 in (38.10 mm)

Depth

2.6 in (66.04 mm)

Environment

Enclosure Rating

NEMA 2

Ambient Operating

149 °F (65 °C)

Ordering and shipping details
