Please read CAUTION and Notice in this catalog for safety. This catalog has only typical specifications. Therefore you are requested

to approve our product specification or to transact the approval sheet for product specification, before your ordering.

P61E7.pdf 01.10.17

Ceramic Filters (CERAFILr) for FM Receivers

CERAFILr Wider Band-width Type

SFELA10M7 Series for FM-receivers are monolithic type

ceramic filters which use the energy trapped thickness

vibration-mode of the piezoelectric ceramic.

s Features

1. Realizes wider or narrower band characteristics not

obtained by conventional ceramic filters.

2. Temperature characteristics are the best available,

the same as those of Murata's conventional ceramic

filters. Thus, even in the case of narrow band

filters, the center frequency is stable even if

temperature changes.

(1)

(2)

(3)

7.0

±2.0

2.5

±0.2

0.5

±0.1

1.7

±0.1

1.38

±0.2

2.5

±0.2

M A R K I N G

E I A J

C O D E

(in mm)

(1) : Input

(2) : Ground

(3) : Output

SFELA10M7EA00-B0

(1)

(2)

(3)

7.0

±2.0

2.5

±0.2

0.5

±0.1

1.7

±0.1

1.38

±0.2

2.5

±0.2

M A R K I N G

E I A J

C O D E

(in mm)

(1) : Input

(2) : Ground

(3) : Output

SFELA10M7DF00-B0

Part Number

Center Frequency (fo)

(MHz)

Nominal

Center Frequency(fn)

(MHz)

3dB Bandwidth

(kHz)

Attenuation

(kHz)

Insertion Loss

(dB)

Spurious Attenuation

(dB)

SFELA10M7EA00-B0

10.700

±30kHz

within330

±50kHz

680 max.

within4.0

±2.0dB

30 min.

SFELA10M7DF00-B0

10.700

±175 min.

950 max.

within3.0

±2.0dB

20 min.

Area of Attenuation : [within 20dB]

Area of Spurious Attenuation : [within 9MHz to 12MHz]

Center frequency(fo) defined by the center of 3dB bandwidth.

(fn) means nominal center frequency.

s Center Frequency Rank Code

CODE

30kHz Step

10.64MHz

±30kHz

10.67MHz

±30kHz

10.70MHz

±30kHz

10.73MHz

±30kHz

10.76MHz

±30kHz

25kHz Step

10.650MHz

±25kHz

10.675MHz

±25kHz

10.700MHz

±25kHz

10.725MHz

±25kHz

10.750MHz

±25kHz

Combination A,B,C,D,E

Combination A,B,C
