Data Sheet

AS03608AS-R

PUI Audio’s Copperhead Series was conceived to create a family sound across

three different speaker sizes: 36mm, 53mm, and 78mm square. Specialized alloy

cones are paired with optimized motors to achieve superior frequency response

and output, with minimized harmonic distortion.

The eight ohm, 36mm square frame AS03608AS-R features a unique spider-less

design for free-flowing cone travel that is controlled by the progressive treated

foam surround.

Features:

•

Coated alloy cone for extended frequency response to 40 kHz

•

78 dB output at 1m (98 dB output at 10cm)

•

High-energy neodymium motor

•

Large 20mm diameter voice coil

•

Easy-to-mount square frame

Specifications

Parameters

Values

Units

Rated Input Power

1

Watts

Max Input Power

2

Watts

Impedance

8 ± 15%

Ohms

Sensitivity (SPL @ 1W/1m)

Avg. at 2, 4, 8, and 16 kHz

78 ± 3

dB

Resonant Frequency

(in free air)

250±20%

Hz

Frequency Range (-10 dB)

150 ~ 40,000

Hz

Frame Material

ABS

-

Magnet Material

NdFeB

-

Weight

29

Grams
