background image
NJM2865/66
-7-
Ver.2004-12-22
ELECTRICAL CHARACTERISTICS
-80
-70
-60
-50
-40
-30
-20
-10
0
0
50
100
150
Output Current : Io(mA)
NJM2865/66_3.0V
Load Regulation vs. Output Current
@:Ta=25
o
C
VIN=4.0V
Co=1.0
µF(Ceramic)
0
50
100
150
200
4
6
8
101214
NJM2865/66_3.0V
Peak Output Current vs. Input Voltage
@:Ta=25
oC
Co=1.0
µF(Ceramic)
Input Voltage : VIN(V)
0
500
1000
1500
2000
0
5
10
15
NJM2865/66_3.0V
Quiescent Current v.s. Input Voltage
@:Ta=25
oC
Output is open.
Co=1.0
µF(Ceramic)
including Icont
Input Voltage : VIN(V)
0
20
40
60
80
100
0.001
0.01
0.1
1
10
100
Output Current : Io(A)
NJM2865/66_3.0V
Output Noise Voltage vs. Output Current
@:Ta=25
o
C
VIN=4.0V
LPF:80kHz
1m
10m
100m
1m
10m
100m
Co=1.0
µF
Co=2.2
µF
20
30
40
50
60
70
80
90
100
10
100
1000
10
4
10
5
Frequency : f (Hz)
NJM2865/66_3.0V
Ripple Rejection Ratio v.s. Frequency
Io=0mA
Io=10mA
Io=30mA
@:Ta=25
oC
VIN=4.0V
ein=200mVrms
Co=1.0
µF(Ceramic)
10
100
1k
10k
100k
