FP0805R1-R10-R Datasheet(PDF) 3 Page - Eaton All Rights Reserved. |
|
|
|||||||||||||||||||||||||||||
FP0805R1-R10-R Datasheet(HTML) 3 Page - Eaton All Rights Reserved. |
|
|
3 / 4 page  3 www.eaton.com/electronics Technical Data 4340 Effective June 2017 Core loss vs Bp-p Inductance characteristics FP0805 High frequency, high current power inductor Temperature rise vs total loss Total Loss (W) 50 40 30 20 10 0 0 0.2 0.4 0.6 0.8 1 1.2 1.4 10 1MHz 500kHz 300kHz 1 200kH 100kHz 0.1 0.01 0.001 0.0001 0.00001 100 1000 10000 Bp-p (Gauss) % of O C L v s. % of Isa t 1 100% -40°C 80% 60% + 25°C 40% + 125°C 20% 0% 0% 20% 40% 60% 80% 100% 120% % of Isa t1 |
|
|
