AC-DC Power Supplies

1 of 1

Creation Date : January 24, 2019 (GMT)

ZWS100BAF-24/R

Sales Region

Worldwide

Series

ZWS-BAF

Status

Production

Feature

Option

Remote ON/OFF control

Option Lineup

Please refer to here.

Recommended EMC Filter Please refer to here.

Accessories

Please refer to the catalog

Electrical Characteristics

Input Voltage Range[AC]

85 to 265V

Input Voltage Range[DC]

120 to 370V

Efficiency

89% Typ.

Rated Output Voltage[DC]

24V

Output Voltage Range[DC]

21.6 to 26.4V

Maximum Output Current

4.3A

Maximum Output Power

103.2W

Cases Shape & Size

Case’ｓ shape

PC board

Width(W)

62mm Nom.

Height(H)

33mm Nom.

Depth(D)

155mm Nom.

Weight

290g Typ.

Other

Operating Temp. Range

-10 to 70°C

Cooling

Convection cooling

Safety Standard(Certified)

UL60950-1

CSA C22.2 No.60950-1

EN60950-1

EN50178 (OV II)

Safety Standard(Conformed)

Den-an

Remarks

This page only shows representative characteristics. Please refer to the

technical data for detailed specifications and conditions.

! Images are for reference only and show exemplary products.

! This PDF document was created based on the data listed on the TDK Corporation website.

! All specifications are subject to change without notice.
