6 / 32 page

AD8260

Data Sheet

Rev. B | Page 6 of 32

ABSOLUTE MAXIMUM RATINGS

Table 2.

Parameter

Rating

Voltage

Supply Voltage (VPOS, VNEG)

±6 V

Input Voltage (INxx, PRAI, FDBK, VMDI,

VOCM)

VPOS, VNEG

Logic Voltages

VPOS, ground

Temperature

Operating Temperature Range

–40°C to +105°C

Storage Temperature Range

–65°C to +150°C

Lead Temperature (Soldering, 60 sec)

300°C

Thermal Data1

Maximum Junction Temperature

125°C

θJA

47.3°C/W

θJC

6.9°C/W

θJB

28.6°C/W

ΨJT

0.6°C/W

ΨJB

27.4°C/W

1 Thermal data at zero airflow with exposed pad soldered to four-layer JEDEC

board with vias per JESD51-5.

Stresses at or above those listed under Absolute Maximum

Ratings may cause permanent damage to the product. This is a

stress rating only; functional operation of the product at these

or any other conditions above those indicated in the operational

section of this specification is not implied. Operation beyond

the maximum operating conditions for extended periods may

affect product reliability.

ESD CAUTION
