background image
Data Sheet
AD8338
Rev. B | Page 11 of 19
0
–10
–100
–90
–80
–70
–60
–50
–40
–30
–20
100
1k
10k
100k
1M
10M
FREQUENCY (Hz)
Figure 34. Power Supply Rejection Ratio (PSRR) vs. Frequency
0.6
0.1
0
–1.0
1.0
0
10
30
40
5
25
20
15
35
TIME (µs)
VAGC VOLTAGE
OUTPUT VOLTAGE
Figure 35. AGC Response vs. Time, No Load, Input 100 mV Differential
0.6
0.1
0
–1.0
1.0
0
2
6
10
9
8
1
5
4
3
7
TIME (ms)
VAGC VOLTAGE
OUTPUT VOLTAGE
Figure 36. AGC Response vs. Time, CL = 0.01 µF, Input 100 mV Differential
3.0
0
0.5
1.0
1.5
2.0
2.5
20k
100k
RESISTANCE (Ω)
VS = 3V
VS = 5V
Figure 37. Output Common-Mode Voltage vs. Common-Mode Resistance
(RCM) to VBAT
3.0
0
0.5
1.0
1.5
2.0
2.5
10k
100k
RESISTANCE (Ω)
VS = 3V
Figure 38. Output Common-Mode Voltage vs. RCM to COMM
