5 / 25 page  Data Sheet ADL5513 Rev. A | Page 5 of 25 Parameter Conditions Min Typ Max Unit FREQUENCY = 2600 MHz Output Voltage: High Power Input PIN = −10 dBm 1.67 V Output Voltage: Low Power Input PIN = −50 dBm 0.83 V ±3.0 dB Dynamic Range 80 dB ±1.0 dB Dynamic Range 74 dB ±0.5 dB Dynamic Range 69 dB Maximum Input Level, ±1.0 dB 7 dBm Minimum Input Level, ±1.0 dB −67 dBm Deviation at TA = 25°C PIN = −10 dBm 0.33 dB PIN = −30 dBm 0.02 dB PIN = −50 dBm 0.01 dB Deviation vs. Temperature Deviation from output at TA = 25°C 25°C < TA < 85°C; PIN = −10 dBm +0.2/−0.4 dB −40°C < TA < +25°C; PIN = −10 dBm +0.05/−0.68 dB 25°C < TA < 125°C; PIN = −10 dBm +0.75/−0.05 dB 25°C < TA < 85°C; PIN = −30 dBm +0.1/−0.37 dB −40°C < TA < +25°C; PIN = −30 dBm +0.25/−0.4 dB 25°C < TA < 125°C; PIN = −30 dBm 0.8 dB 25°C < TA < 85°C; PIN = −50 dBm +0.2/−0.6 dB −40°C < TA < +25°C; PIN = −50 dBm ±0.5 dB 25°C < TA < 125°C; PIN = −50 dBm 1.13 dB Logarithmic Slope 21 mV/dB Logarithmic Intercept −89 dBm Input Impedance 0.4/0.6 kΩ/pF FREQUENCY = 3.6 GHz Output Voltage: High Power Input PIN = −10 dBm 1.74 V Output Voltage: Low Power Input PIN = −50 dBm 0.84 V ±3.0 dB Dynamic Range 76 dB ±1.0 dB Dynamic Range 62 dB ±0.5 dB Dynamic Range 58 dB Maximum Input Level, ±1.0 dB 1 dBm Minimum Input Level, ±1.0 dB −61 dBm Deviation at TA = 25°C PIN = −10 dBm 0.43 dB PIN = −30 dBm −0.05 dB PIN = −50 dBm −0.14 dB Deviation vs. Temperature Deviation from output at TA = 25°C 25°C < TA < 85°C; PIN = −10 dBm +0.32/−0.28 dB −40°C < TA < +25°C; PIN = −10 dBm +0.27/−0.54 dB 25°C < TA < 125°C; PIN = −10 dBm +0.58/−0.21 dB 25°C < TA < 85°C; PIN = −30 dBm +0.3/−0.22 dB −40°C < TA < +25°C; PIN = −30 dBm +0.38/−0.33 dB 25°C < TA < 125°C; PIN = −30 dBm +0.67/−0.05 dB 25°C < TA < 85°C; PIN = −50 dBm +0.41/−0.37 dB −40°C < TA < +25°C; PIN = −50 dBm +0.41/−0.62 dB 25°C < TA < 125°C; PIN = −50 dBm +0.8/−0.18 dB Logarithmic Slope 22.5 mV/dB Logarithmic Intercept −87 dBm Input Impedance 0.5/0.4 kΩ/pF SETPOINT INPUT Pin VSET Nominal Range Log conformance error ≤ ±1 dB, RF input = 8 dBm 2 V Log conformance error ≤ ±1 dB, RF input = −62 dBm 0.58 V Logarithmic Scale Factor 47.1 dB/ V Input Impedance 40 kΩ |
|
|
