STSR30

5/10

Figure 1 : TIMING DIAGRAM

Figure 2 : STSR30 IN FLYBACK CONVERTER SECONDARY SIDE

NOTES

1) Ceramic Capacitors C1 and C2 must be placed very close to the IC;

3) R3 is a pull-up resistor;

4) R5 limits the current flowing through diode D2 when Freewheeling drain voltage is high;

5) D1 could be necessary to protect INHIBIT pin from negative voltages.

7) SGLGND layout trace must not include OUTGATE current paths.

+5V

Vo

Vi

+5V

+5V

Cout

C2

100nF

R1

R2

R5

TRANSFORMER

MosfetN

R3

D3

C1

100nF

D1

D2

STSR30

8

1

3

7

Ck

INHIBIT

SGLGND

SETANT

PWM

Feedback

Loop

option

Low = OFF

High = ON
