Section 13 I/O Ports
Rev. 2.00 Sep. 24, 2008 Page 634 of 1468
REJ09B0412-0200
13.2.8
Port C
(1)
PC3/
LLCAS/DQMLL
The pin function is switched as shown below according to the combination of operating mode, the
EXPE bit, the bus controller register, and the PC3DDR bit settings.
Setting
Bus Controller
I/O Port
Module Name
Pin Function
LLCAS_OE
DQMLL_OE
PC3DDR
LLCAS output*
1
Bus controller
DQMLL output*
1
PC3 output
0
0
1
I/O port
PC3 input
(initial value)
0
0
0
Note:
*
Valid in external extended mode (EXPE = 1)
(2)
PC2/
LUCAS/DQMLU
The pin function is switched as shown below according to the combination of operating mode, the
EXPE bit, the bus controller register, and the PC2DDR bit settings.
Setting
Bus Controller
I/O Port
Module Name
Pin Function
LUCAS_OE
DQMLU_OE
PC2DDR
LUCAS output*
1
Bus controller
DQMLU output*
1
PC2 output
0
0
1
I/O port
PC2 input
(initial value)
0
0
0
Note:
*
Valid in external extended mode (EXPE = 1)
