Section 11 EXDMA Controller (EXDMAC)
Rev. 2.00 Sep. 24, 2008 Page 523 of 1468
REJ09B0412-0200
Figures 11.44 to 11.47 show operation timing examples for various conditions.
3 cycles
Last transfer cycle
B
φ
EDREQ
EDRAK
Bus cycle
ETEND
DTE bit
Bus release
Bus release
EXDMA
read
EXDMA
write
Bus release
EXDMA
read
EXDMA
write
0
1
Figure 11.44 External Request/Normal Transfer Mode/Cycle Steal Mode
(No Conflict/Dual Address Mode/Low Level Sensing)
One bus cycle
Last transfer cycle
B
φ
EDREQ
EDRAK
Bus cycle
ETEND
EDACK
CPU operation
CPU cycle
CPU cycle
EXDMAC single
transfer cycle
CPU cycle
CPU cycle
EXDMAC single
transfer cycle
External
space
External space
External space
External
space
Figure 11.45 External Request/Normal Transfer Mode/Cycle Steal Mode
(CPU Cycles/Single Address Mode/Low Level Sensing)
